Features
Sensitivity : 86 – 89 dB / watt / m
Nom. impedance : 6 ohms
SE Version
- Twin 13″ long throw bass drivers with ultra hard injection moulded diaphragm in sealed enclosure, driven by 2 x 350 W Class D amplifier module with programmable DSP and 4 user-selectable presets for optimal integration in any listening room
- 6″ custom-made woodcone bass-midrange driver with 16-cm electromechanical parallel spiral resonator, 1st order low pass filter, no high pass filter, ash tree phase plug, magnet structure force fit mounted to the whole wooden mass of enclosure
- 3″ custom-made widebander, 1st order high pass filter, unique 16-cm electromechanical parallel spiral resonator installed
- Lessloss C-Marc internal wiring
- WBT NextGen binding posts
- Rear ambient tweeter
- Added latest generation Bybee Quantum Purifiers
- Added proprietary phase linearization network
- Mundorf Silver Gold Oil capacitor for widebander
- Added Duelund Tinned Copper Foil 0.01 uF bypass capacitor
- Swing Base included
SE + Version
- 16-cm spiral resonator installed at widebander and bass-midrange driver both parallel and in series
- Added Steinmusic Speaker Match Signature
- Added Harmonix RF 5700 Tuning Bases to widebander
- One more Bybee Quantum Purifier added, now directly placed before positive driver terminal
- Duelund pure Tinned Copper Foil main capacitor for widebander
- Mundorf Silver Gold Oil capacitor for rear tweeter
- 3 Lessloss Firewall for speakers filters installed
- C37 lacquer on rear side of wood cone and inner side of voice coil former
- Swing Base included
